Digitimer NL703 Neurolog EMG Integrator

Description

The NL703 EMG Integrator module was designed to produce an analogue signal to represent the amount or strength of muscle activity. The unit accepts signals up to +1V, which are first full wave rectified and then applied to a “leaky integrator” within the module. The output of the integrator is buffered and the overall gain is set at unity. The time constant of the integrator is selected by a 6 position rotary switch. A toggle switch is also provided so that the direct signal can be viewed.

Manufacturer: Digitimer
Catalog number: NL703
Parent Category: NeuroLog System
Application: Amplifiers & Stimulators

For full web page, please see https://www.autom8.com/amplifiers-stimulators-overview/neurolog-modular-system

Download a User's Manual at https://www.autom8.com/wp-content/uploads/2016/07/Manual-All-NeuroLog.pdf

Download a brochure at https://www.autom8.com/wp-content/uploads/2016/07/NeuroLog.pdf
